Maneuver::FollowReference::UAV::Task Struct Reference

Public Member Functions

 Task (const std::string &name, Tasks::Context &ctx)

void consume (const IMC::FollowReference *msg)

void consume (const IMC::Reference *msg)

void consume (const IMC::EstimatedState *msg)

void onPathControlState (const IMC::PathControlState *pcs)

bool sameReference (const IMC::Reference *msg1, const IMC::Reference *msg2)

IMC::SpeedUnits parseSpeedUnitsStr (std::string sunits_str)

void processDesiredPath (void)

void enableMovement (bool enable)

void updateEndLoc (void)

void updateSpeed (void)

void updateRadius (void)

void updateEndZ (void)

int initializeEndZ (void)

void updateCoordinates (void)

void dispatchDesiredPath (void)

void updateFollowRefStateFlags (void)

void checkTimeout (void)

bool offlineOrWaiting (void)

void onDeactivation (void)

- Public Member Functions inherited from DUNE::IMC::Message
 Message (void)

virtual ~Message (void)

virtual Messageclone (void) const =0

virtual void clear (void)=0

virtual int validate (void) const =0

virtual const char * getName (void) const =0

virtual uint16_t getId (void) const =0

double setTimeStamp (double ts)

double setTimeStamp (void)

double getTimeStamp (void) const

uint16_t getSource (void) const

void setSource (uint16_t src)

uint8_t getSourceEntity (void) const

void setSourceEntity (uint8_t src_ent)

uint16_t getDestination (void) const

void setDestination (uint16_t dst)

uint8_t getDestinationEntity (void) const

void setDestinationEntity (uint8_t dst_ent)

virtual uint16_t getSubId (void) const

virtual void setSubId (uint16_t subid)

virtual fp64_t getValueFP (void) const

virtual void setValueFP (fp64_t val)

unsigned getSerializationSize (void) const

unsigned getPayloadSerializationSize (void) const

virtual unsigned getFixedSerializationSize (void) const

virtual unsigned getVariableSerializationSize (void) const

void toJSON (std::ostream &os) const

void toText (std::ostream &os) const

virtual uint8_t * serializeFields (uint8_t *bfr) const =0

virtual uint16_t deserializeFields (const uint8_t *bfr, uint16_t len)=0

virtual uint16_t reverseDeserializeFields (const uint8_t *bfr, uint16_t len)=0

virtual void fieldsToJSON (std::ostream &os, unsigned indent_level) const

bool operator== (const Message &other) const

bool operator!= (const Message &other) const


Public Attributes

IMC::FollowReference m_spec

IMC::Reference m_cur_ref

double m_last_ref_time

IMC::EstimatedState m_estate

IMC::PathControlState m_pcs

IMC::FollowRefState m_fref_state

IMC::DesiredPath m_desired_path

Arguments m_args


Additional Inherited Members

- Protected Member Functions inherited from DUNE::IMC::Message
virtual void setTimeStampNested (double value)

virtual void setSourceNested (uint16_t value)

virtual void setSourceEntityNested (uint8_t value)

virtual void setDestinationNested (uint16_t value)

virtual void setDestinationEntityNested (uint8_t value)

virtual bool fieldsEqual (const Message &other) const

- Protected Attributes inherited from DUNE::IMC::Message
Header m_header


Constructor & Destructor Documentation

Member Function Documentation

void Maneuver::FollowReference::UAV::Task::checkTimeout ( void  )
inline

Check timeout.

References m_fref_state, m_last_ref_time, and m_spec.

Referenced by consume().

void Maneuver::FollowReference::UAV::Task::consume ( const IMC::FollowReference *  msg)
inline
void Maneuver::FollowReference::UAV::Task::consume ( const IMC::Reference *  msg)
inline
void Maneuver::FollowReference::UAV::Task::consume ( const IMC::EstimatedState *  msg)
inline

References checkTimeout(), and m_estate.

void Maneuver::FollowReference::UAV::Task::dispatchDesiredPath ( void  )
inline

Dispatch desired path message.

References enableMovement(), m_desired_path, and m_fref_state.

Referenced by processDesiredPath().

void Maneuver::FollowReference::UAV::Task::enableMovement ( bool  enable)
inline

Function for enabling and disabling the control loops.

Referenced by dispatchDesiredPath().

int Maneuver::FollowReference::UAV::Task::initializeEndZ ( void  )
inline

Initialize end z.

Returns
desired height.

References Maneuver::FollowReference::UAV::Arguments::default_z, m_args, and m_estate.

Referenced by updateEndZ().

bool Maneuver::FollowReference::UAV::Task::offlineOrWaiting ( void  )
inline

Check if follow reference state has either timed out or is waiting.

Returns
true if timed out or waiting, false otherwise.

References m_fref_state.

Referenced by updateFollowRefStateFlags().

void Maneuver::FollowReference::UAV::Task::onDeactivation ( void  )
inline

References m_fref_state.

void Maneuver::FollowReference::UAV::Task::onPathControlState ( const IMC::PathControlState *  pcs)
inline
IMC::SpeedUnits Maneuver::FollowReference::UAV::Task::parseSpeedUnitsStr ( std::string  sunits_str)
inline

Parse speed units string.

Parameters
[in]sunits_strspeed units string.
Returns
desired speed units.

Referenced by updateSpeed().

void Maneuver::FollowReference::UAV::Task::processDesiredPath ( void  )
inline

Generate and dispatch a DesiredPath based on the received reference.

References dispatchDesiredPath(), m_cur_ref, updateCoordinates(), updateEndLoc(), updateEndZ(), updateRadius(), and updateSpeed().

Referenced by consume().

bool Maneuver::FollowReference::UAV::Task::sameReference ( const IMC::Reference *  msg1,
const IMC::Reference *  msg2
)
inline

Check if references are equal.

Parameters
[in]msg1reference message.
[in]msg2reference message.
Returns
true if references are equal, false otherwise.

Referenced by consume().

void Maneuver::FollowReference::UAV::Task::updateCoordinates ( void  )
inline

Update desired path's coordinates.

References m_cur_ref, and m_desired_path.

Referenced by processDesiredPath().

void Maneuver::FollowReference::UAV::Task::updateEndLoc ( void  )
inline

Update desired path's end location.

References m_cur_ref, and m_desired_path.

Referenced by processDesiredPath().

void Maneuver::FollowReference::UAV::Task::updateEndZ ( void  )
inline

Update desired path's end z.

References initializeEndZ(), m_cur_ref, and m_desired_path.

Referenced by processDesiredPath().

void Maneuver::FollowReference::UAV::Task::updateFollowRefStateFlags ( void  )
inline

Update follow reference state flags.

References m_fref_state, m_pcs, and offlineOrWaiting().

Referenced by onPathControlState().

void Maneuver::FollowReference::UAV::Task::updateRadius ( void  )
inline
void Maneuver::FollowReference::UAV::Task::updateSpeed ( void  )
inline

Member Data Documentation

Arguments Maneuver::FollowReference::UAV::Task::m_args
IMC::Reference Maneuver::FollowReference::UAV::Task::m_cur_ref

Store latest received reference and the one before that.

Referenced by consume(), processDesiredPath(), updateCoordinates(), updateEndLoc(), updateEndZ(), updateRadius(), and updateSpeed().

IMC::DesiredPath Maneuver::FollowReference::UAV::Task::m_desired_path
IMC::EstimatedState Maneuver::FollowReference::UAV::Task::m_estate

Estimated state.

Referenced by consume(), and initializeEndZ().

IMC::FollowRefState Maneuver::FollowReference::UAV::Task::m_fref_state
double Maneuver::FollowReference::UAV::Task::m_last_ref_time

Store last timestamp when reference was received.

Referenced by checkTimeout(), consume(), and Task().

IMC::PathControlState Maneuver::FollowReference::UAV::Task::m_pcs

Path Control state.

Referenced by onPathControlState(), and updateFollowRefStateFlags().

IMC::FollowReference Maneuver::FollowReference::UAV::Task::m_spec

Store maneuver specification.

Referenced by checkTimeout(), and consume().

Collaboration diagram for Maneuver::FollowReference::UAV::Task:
Collaboration graph
