DUNE::Network::UDPSocket Class Reference

Detailed Description

UDP Socket.

Public Member Functions
	UDPSocket (void)
	~UDPSocket (void)
void	enableBroadcast (bool value)
void	setMulticastTTL (uint8_t ttl=1)
void	setMulticastLoop (bool loopback=true)
void	joinMulticastGroup (Address group, Address itf=Address::Any)
void	bind (uint16_t port=0, Address add=Address::Any, bool reuse=true)
void	connect (const Address &addr, uint16_t port)
size_t	write (const uint8_t *buffer, size_t size, const Address &addr, uint16_t port)
size_t	read (uint8_t *buffer, size_t size, Address *addr=NULL, uint16_t *port=NULL)
Public Member Functions inherited from DUNE::IO::Handle
virtual	~Handle (void)
size_t	write (const uint8_t *data, size_t length)
size_t	write (const char *data, size_t length)
size_t	writeString (const char *cstr)
size_t	read (uint8_t *data, size_t length)
size_t	read (char *data, size_t length)
size_t	readString (char *bfr, size_t length)
void	flush (void)
void	flushInput (void)
void	flushOutput (void)
NativeHandle	getNative (void) const

Additional Inherited Members
Protected Member Functions inherited from DUNE::IO::Handle
virtual void	doFlushInput (void)
virtual void	doFlushOutput (void)
virtual void	doFlush (void)

Constructor & Destructor Documentation

UDPSocket()

DUNE::Network::UDPSocket::UDPSocket

(

void

)

Create an unbound UDP socket.

References DUNE::NotImplemented.

Referenced by connect().

~UDPSocket()

DUNE::Network::UDPSocket::~UDPSocket

(

void

)

Destroy an UDP socket.

Member Function Documentation

bind()

void DUNE::Network::UDPSocket::bind	(	uint16_t	port = 0,
		Address	add = Address::Any,
		bool	reuse = true
	)

Assign a name to a socket.

References DUNE::Utils::ByteCopy::toBE(), and DUNE::Network::Address::toInteger().

connect()

void DUNE::Network::UDPSocket::connect ( const Address &  addr, uint16_t  port  )

inline

References read(), UDPSocket(), and write().

enableBroadcast()

void DUNE::Network::UDPSocket::enableBroadcast

(

bool

value

)

joinMulticastGroup()

void DUNE::Network::UDPSocket::joinMulticastGroup	(	Address	group,
		Address	itf = Address::Any
	)

References DUNE::Network::Address::toInteger().

read()

size_t DUNE::Network::UDPSocket::read	(	uint8_t *	buffer,
		size_t	size,
		Address *	addr = NULL,
		uint16_t *	port = NULL
	)

Receive an UDP datagram, retrieving the address of the source host.

Parameters

buffer	destination buffer.
size	destination buffer length.
addr	system specific host address.
port	system specific host port.

References DUNE::Utils::ByteCopy::fromBE().

Referenced by connect().

setMulticastLoop()

void DUNE::Network::UDPSocket::setMulticastLoop

(

bool

loopback = true

)

setMulticastTTL()

void DUNE::Network::UDPSocket::setMulticastTTL

(

uint8_t

ttl = 1

)

write()

size_t DUNE::Network::UDPSocket::write	(	const uint8_t *	buffer,
		size_t	size,
		const Address &	addr,
		uint16_t	port
	)

Send an UDP datagram to a host.

Parameters

buffer	buffer to send.
size	buffer length.
addr	system specific host address.
port	destination port.

References DUNE::Network::Address::str(), DUNE::Utils::ByteCopy::toBE(), and DUNE::Network::Address::toInteger().

Referenced by connect().

Collaboration diagram for DUNE::Network::UDPSocket:
