Control::UAV::PX4::Task Struct Reference

Public Types

typedef void(Task::* PktHandler) (const mavlink_message_t *msg)

typedef std::map< int, PktHandler > PktHandlerMap

- Public Types inherited from DUNE::Concurrency::Runnable

Public Member Functions

 Task (const std::string &name, Tasks::Context &ctx)

void onResourceAcquisition (void)

void openConnection (void)

void onResourceRelease (void)

void onUpdateParameters (void)

void consume (const IMC::AutopilotMode *msg)

void clearMission (void)

void sendCommandPacket (uint16_t cmd, float arg1=0, float arg2=0, float arg3=0, float arg4=0, float arg5=0, float arg6=0, float arg7=0)

void consume (const IMC::DevCalibrationControl *msg)

void consume (const IMC::ControlLoops *cloops)

void consume (const IMC::PlanControl *msg)

void consume (const IMC::Loiter *msg)

void consume (const IMC::VehicleState *msg)

void consume (const IMC::Announce *msg)

void consume (const IMC::Takeoff *tkoff)

void consume (const IMC::Land *land)

void consume (const IMC::DesiredPath *path)

void onMain (void)

void handleArdupilotData (void)

void checkParseState (mavlink_status_t &status)

bool poll (double timeout)

int sendData (uint8_t *bfr, int size)

int receiveData (uint8_t *buf, size_t blen)

void handleAttitudePacket (const mavlink_message_t *msg)

void handleImuRaw (const mavlink_message_t *msg)

void handlePositionPacket (const mavlink_message_t *msg)

void handleHWStatusPacket (const mavlink_message_t *msg)

void handleSystemStatusPacket (const mavlink_message_t *msg)

void handleScaledPressurePacket (const mavlink_message_t *msg)

void handleWindPacket (const mavlink_message_t *msg)

void handleStatusTextPacket (const mavlink_message_t *msg)

void handleHeartbeatPacket (const mavlink_message_t *msg)

void handleHUDPacket (const mavlink_message_t *msg)

void handleRawGPSPacket (const mavlink_message_t *msg)

void handleSystemTimePacket (const mavlink_message_t *msg)

void handleExtendedStatePacket (const mavlink_message_t *msg)

void handleMissionAckPacket (const mavlink_message_t *msg)

void handleMissionItemReachedPacket (const mavlink_message_t *msg)

void handleNavControllerPacket (const mavlink_message_t *msg)

- Public Member Functions inherited from DUNE::Tasks::Task
 Task (const std::string &name, Context &context)

virtual ~Task (void)

const char * getName (void) const

const char * getSystemName (void) const

unsigned int getSystemId (void) const

unsigned int getEntityId (void) const

unsigned int resolveEntity (const std::string &label) const

std::string resolveEntity (unsigned int id) const

DebugLevel getDebugLevel (void) const

uint16_t getActivationTime (void) const

uint16_t getDeactivationTime (void) const

unsigned int resolveSystemName (const std::string &name) const

const char * resolveSystemId (unsigned int id) const

void loadConfig (void)

void setPriority (unsigned int value)

unsigned int getPriority (void) const

void inf (const char *format,...) DUNE_PRINTF_FORMAT(2

void void war (const char *format,...) DUNE_PRINTF_FORMAT(2

void void void err (const char *format,...) DUNE_PRINTF_FORMAT(2

void void void void cri (const char *format,...) DUNE_PRINTF_FORMAT(2

void void void void void debug (const char *format,...) DUNE_PRINTF_FORMAT(2

void void void void void void trace (const char *format,...) DUNE_PRINTF_FORMAT(2

void void void void void void void spew (const char *format,...) DUNE_PRINTF_FORMAT(2

void void void void void void void void dispatch (IMC::Message *msg, unsigned int flags=0)

void dispatch (IMC::Message &msg, unsigned int flags=0)

void dispatchReply (const IMC::Message &original, IMC::Message &msg, unsigned int flags=0)

void receive (const IMC::Message *msg)

void reserveEntities (void)

void resolveEntities (void)

void acquireResources (void)

void releaseResources (void)

void initializeResources (void)

void updateParameters (bool act_deact=true)

void writeParamsXML (std::ostream &os) const

const char * getEntityLabel (void) const

void setEntityLabel (const std::string &label)

- Public Member Functions inherited from DUNE::Tasks::AbstractTask
 AbstractTask (void)

virtual ~AbstractTask (void)

- Public Member Functions inherited from DUNE::Concurrency::Thread
 Thread (void)

virtual ~Thread (void)

int getProcessorUsage (void)

- Public Member Functions inherited from DUNE::Concurrency::Runnable
 Runnable (void)

virtual ~Runnable (void)

void start (void)

void stop (void)

void join (void)

void stopAndJoin (void)

void setPriority (Scheduler::Policy policy, unsigned priority)

unsigned getPriority (void)

State getState (void)

bool isCreated (void)

bool isStopping (void)

bool isRunning (void)

bool isStarting (void)

bool isDead (void)


Public Attributes

Arguments m_args

PktHandlerMap m_mlh

bool m_mission

float m_hae_offset

bool m_offset

int m_duration

bool m_maneuver

Network::TCPSocket * m_TCP_sock

Network::UDPSocket * m_UDP_sock

uint8_t m_sysid

mavlink_message_t m_msg

uint8_t m_buf [512]

VTOL_State m_vtol_state

Time::Counter< float > m_timer

bool m_error_missing

double m_last_pkt_time

double m_last_wp

IMC::GpsFix m_fix

IMC::EstimatedState m_estate

IMC::DesiredPath m_dpath

IMC::PathControlState m_pcs

IMC::AutopilotMode m_mode

IMC::TrueSpeed m_groundspeed

IMC::ControlLoops m_cloops


Additional Inherited Members

- Protected Member Functions inherited from DUNE::Tasks::Task
void setEntityState (IMC::EntityState::StateEnum state, Status::Code code)

void setEntityState (IMC::EntityState::StateEnum state, const std::string &description)

IMC::EntityState::StateEnum getEntityState (void) const

unsigned int reserveEntity (const std::string &label)

template<typename E >
E * reserveEntity (const std::string &label)

Entities::BasicEntity * getLocalEntity (const std::string &label)

bool stopping (void)

bool isActive (void) const

bool isActivating (void) const

bool isDeactivating (void) const

void waitForMessages (double timeout)

void consumeMessages (void)

template<typename T >
Parameter & param (const std::string &name, T &var)

template<typename Y , typename T >
Parameter & param (const std::string &name, T &var)

template<typename T >
bool paramChanged (T &var)

void paramActive (Parameter::Scope def_scope, Parameter::Visibility def_visibility, bool def_value=false)

void setParamSectionEditor (const std::string &name)

template<typename M , typename T >
void bind (T *task_obj, void(T::*consumer)(const M *)=&T::consume)

template<typename T >
void bind (T *task_obj, const std::vector< uint32_t > &list)

template<typename T , typename M >
void bind (T *task_obj, const std::vector< uint32_t > &list, void(T::*consumer)(const M *)=&T::consume)

template<typename T >
void bind (T *task_obj, const std::vector< std::string > &list)

void requestActivation (void)

void requestDeactivation (void)

void activate (void)

void activationFailed (const std::string &reason)

void deactivate (void)

void deactivationFailed (const std::string &reason)

virtual bool onWriteParamsXML (std::ostream &os) const

virtual void onEntityReservation (void)

virtual void onEntityResolution (void)

virtual void onReportEntityState (void)

virtual void onResourceInitialization (void)

virtual void onRequestActivation (void)

virtual void onRequestDeactivation (void)

virtual void onActivation (void)

virtual void onDeactivation (void)

virtual void onQueryEntityParameters (const IMC::QueryEntityParameters *msg)

virtual void onSetEntityParameters (const IMC::SetEntityParameters *msg)

virtual void onPushEntityParameters (const IMC::PushEntityParameters *msg)

virtual void onPopEntityParameters (const IMC::PopEntityParameters *msg)

- Protected Member Functions inherited from DUNE::Concurrency::Thread
void startImpl (void)

void stopImpl (void)

void joinImpl (void)

void setPriorityImpl (Scheduler::Policy policy, unsigned priority)

unsigned getPriorityImpl (void)

- Protected Attributes inherited from DUNE::Tasks::Task
Context & m_ctx

std::vector< Entities::BasicEntity * > m_entities


Member Typedef Documentation

typedef void(Task::* Control::UAV::PX4::Task::PktHandler) (const mavlink_message_t *msg)

Type definition for PX4 packet handler.

typedef std::map<int, PktHandler> Control::UAV::PX4::Task::PktHandlerMap

Constructor & Destructor Documentation

Control::UAV::PX4::Task::Task ( const std::string &  name,
Tasks::Context &  ctx
)
inline

Constructor.

Parameters
[in]nametask name.
[in]ctxcontext.

References Control::UAV::PX4::Arguments::basestation, Control::UAV::PX4::Arguments::comm_timeout, handleAttitudePacket(), handleExtendedStatePacket(), handleHeartbeatPacket(), handleHUDPacket(), handleHWStatusPacket(), handleImuRaw(), handleMissionAckPacket(), handleMissionItemReachedPacket(), handleNavControllerPacket(), handlePositionPacket(), handleRawGPSPacket(), handleScaledPressurePacket(), handleStatusTextPacket(), handleSystemStatusPacket(), handleSystemTimePacket(), handleWindPacket(), Control::UAV::PX4::Arguments::heartbeat, Control::UAV::PX4::Arguments::home_update, Control::UAV::PX4::Arguments::ip, Control::UAV::PX4::Arguments::mavlink_phototrigger, Control::UAV::PX4::Arguments::moving_home, Control::UAV::PX4::Arguments::TCP_addr, Control::UAV::PX4::Arguments::tcp_or_udp, Control::UAV::PX4::Arguments::TCP_port, Control::UAV::PX4::Arguments::threshold_fw, Control::UAV::PX4::Arguments::threshold_mc, Control::UAV::PX4::Arguments::transition_fw, Control::UAV::PX4::Arguments::transition_mc, Control::UAV::PX4::Arguments::UDP_addr, Control::UAV::PX4::Arguments::UDP_listen_port, and Control::UAV::PX4::Arguments::UDP_port.

Member Function Documentation

void Control::UAV::PX4::Task::checkParseState ( mavlink_status_t &  status)
inline
void Control::UAV::PX4::Task::clearMission ( void  )
inline
void Control::UAV::PX4::Task::consume ( const IMC::AutopilotMode *  msg)
inline
void Control::UAV::PX4::Task::consume ( const IMC::DevCalibrationControl *  msg)
inline
void Control::UAV::PX4::Task::consume ( const IMC::ControlLoops *  cloops)
inline

References Control::UAV::PX4::PX4_CUSTOM_MAIN_MODE_AUTO, and Control::UAV::PX4::PX4_CUSTOM_SUB_MODE_AUTO_LOITER.

void Control::UAV::PX4::Task::consume ( const IMC::PlanControl *  msg)
inline
void Control::UAV::PX4::Task::consume ( const IMC::Loiter *  msg)
inline
void Control::UAV::PX4::Task::consume ( const IMC::VehicleState *  msg)
inline
void Control::UAV::PX4::Task::consume ( const IMC::Announce *  msg)
inline

References Control::UAV::PX4::Arguments::basestation, and Control::UAV::PX4::Arguments::moving_home.

void Control::UAV::PX4::Task::consume ( const IMC::Takeoff *  tkoff)
inline

References Control::UAV::PX4::PX4_CUSTOM_MAIN_MODE_AUTO, and Control::UAV::PX4::PX4_CUSTOM_SUB_MODE_AUTO_TAKEOFF.

void Control::UAV::PX4::Task::consume ( const IMC::Land *  land)
inline

References Control::UAV::PX4::PX4_CUSTOM_MAIN_MODE_AUTO, and Control::UAV::PX4::PX4_CUSTOM_SUB_MODE_AUTO_LAND.

void Control::UAV::PX4::Task::consume ( const IMC::DesiredPath *  path)
inline

Message for AUTO(MISSION) control (using PX4's controllers)

References Control::UAV::PX4::MAV_VTOL_STATE_FW, Control::UAV::PX4::MAV_VTOL_STATE_MC, Control::UAV::PX4::PX4_CUSTOM_MAIN_MODE_AUTO, Control::UAV::PX4::PX4_CUSTOM_SUB_MODE_AUTO_MISSION, Control::UAV::PX4::Arguments::transition_fw, and Control::UAV::PX4::Arguments::transition_mc.

void Control::UAV::PX4::Task::handleArdupilotData ( void  )
inline

References Control::UAV::PX4::Arguments::comm_timeout.

void Control::UAV::PX4::Task::handleAttitudePacket ( const mavlink_message_t *  msg)
inline

Referenced by Task().

void Control::UAV::PX4::Task::handleExtendedStatePacket ( const mavlink_message_t *  msg)
inline

Referenced by Task().

void Control::UAV::PX4::Task::handleHeartbeatPacket ( const mavlink_message_t *  msg)
inline

References Control::UAV::PX4::Arguments::heartbeat, Control::UAV::PX4::PX4_CUSTOM_MAIN_MODE_ACRO, Control::UAV::PX4::PX4_CUSTOM_MAIN_MODE_ALTCTL, Control::UAV::PX4::PX4_CUSTOM_MAIN_MODE_AUTO, Control::UAV::PX4::PX4_CUSTOM_MAIN_MODE_MANUAL, Control::UAV::PX4::PX4_CUSTOM_MAIN_MODE_OFFBOARD, Control::UAV::PX4::PX4_CUSTOM_MAIN_MODE_POSCTL, Control::UAV::PX4::PX4_CUSTOM_MAIN_MODE_RATTITUDE, Control::UAV::PX4::PX4_CUSTOM_MAIN_MODE_STABILIZED, Control::UAV::PX4::PX4_CUSTOM_SUB_MODE_AUTO_FOLLOW_TARGET, Control::UAV::PX4::PX4_CUSTOM_SUB_MODE_AUTO_LAND, Control::UAV::PX4::PX4_CUSTOM_SUB_MODE_AUTO_LOITER, Control::UAV::PX4::PX4_CUSTOM_SUB_MODE_AUTO_MISSION, Control::UAV::PX4::PX4_CUSTOM_SUB_MODE_AUTO_RTL, and Control::UAV::PX4::PX4_CUSTOM_SUB_MODE_AUTO_TAKEOFF.

Referenced by Task().

void Control::UAV::PX4::Task::handleHUDPacket ( const mavlink_message_t *  msg)
inline

Referenced by Task().

void Control::UAV::PX4::Task::handleHWStatusPacket ( const mavlink_message_t *  msg)
inline

Referenced by Task().

void Control::UAV::PX4::Task::handleImuRaw ( const mavlink_message_t *  msg)
inline

Referenced by Task().

void Control::UAV::PX4::Task::handleMissionAckPacket ( const mavlink_message_t *  msg)
inline

Referenced by Task().

void Control::UAV::PX4::Task::handleMissionItemReachedPacket ( const mavlink_message_t *  msg)
inline

References Control::UAV::PX4::PX4_CUSTOM_MAIN_MODE_AUTO, and Control::UAV::PX4::PX4_CUSTOM_SUB_MODE_AUTO_LOITER.

Referenced by Task().

void Control::UAV::PX4::Task::handleNavControllerPacket ( const mavlink_message_t *  msg)
inline

References Control::UAV::PX4::MAV_VTOL_STATE_FW, Control::UAV::PX4::Arguments::threshold_fw, and Control::UAV::PX4::Arguments::threshold_mc.

Referenced by Task().

void Control::UAV::PX4::Task::handlePositionPacket ( const mavlink_message_t *  msg)
inline

Referenced by Task().

void Control::UAV::PX4::Task::handleRawGPSPacket ( const mavlink_message_t *  msg)
inline

Referenced by Task().

void Control::UAV::PX4::Task::handleScaledPressurePacket ( const mavlink_message_t *  msg)
inline

Referenced by Task().

void Control::UAV::PX4::Task::handleStatusTextPacket ( const mavlink_message_t *  msg)
inline

Referenced by Task().

void Control::UAV::PX4::Task::handleSystemStatusPacket ( const mavlink_message_t *  msg)
inline

Referenced by Task().

void Control::UAV::PX4::Task::handleSystemTimePacket ( const mavlink_message_t *  msg)
inline

Referenced by Task().

void Control::UAV::PX4::Task::handleWindPacket ( const mavlink_message_t *  msg)
inline

Referenced by Task().

void Control::UAV::PX4::Task::onMain ( void  )
inlinevirtual

Main loop.

Implements DUNE::Tasks::Task.

void Control::UAV::PX4::Task::onResourceAcquisition ( void  )
inlinevirtual

Acquire resources.

Reimplemented from DUNE::Tasks::Task.

References Control::UAV::PX4::Arguments::ip, and Control::UAV::PX4::Arguments::TCP_port.

void Control::UAV::PX4::Task::onResourceRelease ( void  )
inlinevirtual

Release resources.

Reimplemented from DUNE::Tasks::Task.

void Control::UAV::PX4::Task::onUpdateParameters ( void  )
inlinevirtual

Called when the task is instructed to update its run-time parameters.

Derived classes that need to compute auxiliary values based on run-time parameters should override this function.

Reimplemented from DUNE::Tasks::Task.

References Control::UAV::PX4::Arguments::home_update, Control::UAV::PX4::Arguments::mavlink_phototrigger, and Control::UAV::PX4::Arguments::moving_home.

void Control::UAV::PX4::Task::openConnection ( void  )
inline

References Control::UAV::PX4::Arguments::TCP_addr, Control::UAV::PX4::Arguments::tcp_or_udp, Control::UAV::PX4::Arguments::TCP_port, and Control::UAV::PX4::Arguments::UDP_listen_port.

bool Control::UAV::PX4::Task::poll ( double  timeout)
inline
int Control::UAV::PX4::Task::receiveData ( uint8_t *  buf,
size_t  blen
)
inline

References Control::UAV::PX4::Arguments::TCP_addr, Control::UAV::PX4::Arguments::tcp_or_udp, Control::UAV::PX4::Arguments::TCP_port, Control::UAV::PX4::Arguments::UDP_addr, and Control::UAV::PX4::Arguments::UDP_listen_port.

void Control::UAV::PX4::Task::sendCommandPacket ( uint16_t  cmd,
float  arg1 = 0,
float  arg2 = 0,
float  arg3 = 0,
float  arg4 = 0,
float  arg5 = 0,
float  arg6 = 0,
float  arg7 = 0
)
inline
int Control::UAV::PX4::Task::sendData ( uint8_t *  bfr,
int  size
)
inline

References Control::UAV::PX4::Arguments::UDP_addr, and Control::UAV::PX4::Arguments::UDP_port.

Member Data Documentation

Arguments Control::UAV::PX4::Task::m_args

Task arguments.

uint8_t Control::UAV::PX4::Task::m_buf[512]
IMC::ControlLoops Control::UAV::PX4::Task::m_cloops

ControlLoops message.

IMC::DesiredPath Control::UAV::PX4::Task::m_dpath

DesiredPath message.

int Control::UAV::PX4::Task::m_duration

Loiter maneuver duration.

bool Control::UAV::PX4::Task::m_error_missing

Mavlink Timeouts.

IMC::EstimatedState Control::UAV::PX4::Task::m_estate

Estimated state message.

IMC::GpsFix Control::UAV::PX4::Task::m_fix

GPS Fix message.

IMC::TrueSpeed Control::UAV::PX4::Task::m_groundspeed

TrueSpeed message.

float Control::UAV::PX4::Task::m_hae_offset

Height offset between MSL and WGS84.

double Control::UAV::PX4::Task::m_last_pkt_time
double Control::UAV::PX4::Task::m_last_wp
bool Control::UAV::PX4::Task::m_maneuver

Vehicle State is "Maneuver".

bool Control::UAV::PX4::Task::m_mission

Flag of mission mode.

PktHandlerMap Control::UAV::PX4::Task::m_mlh

PX4 packet handling.

IMC::AutopilotMode Control::UAV::PX4::Task::m_mode

AutopilotMode message.

mavlink_message_t Control::UAV::PX4::Task::m_msg

Parser Variables.

bool Control::UAV::PX4::Task::m_offset

Flag to signal if MSL-WGS84 offset has already been calculated.

IMC::PathControlState Control::UAV::PX4::Task::m_pcs

PathControlState message.

uint8_t Control::UAV::PX4::Task::m_sysid

System ID.

Network::TCPSocket* Control::UAV::PX4::Task::m_TCP_sock

TCP socket.

Time::Counter<float> Control::UAV::PX4::Task::m_timer

Moving Home timer.

Network::UDPSocket* Control::UAV::PX4::Task::m_UDP_sock

UDP socket.

VTOL_State Control::UAV::PX4::Task::m_vtol_state

VTOL State.

Collaboration diagram for Control::UAV::PX4::Task:
Collaboration graph
